| No. | Category | Part Number | Package size | Image | Application | Parameter | Specification(PDF) |
|---|---|---|---|---|---|---|---|
| 1 | WS2814 Family | WS2814 Family | SOP12/SSOP10，SOP8/ SOT23-8 |  |
Applications
● LED full color decorative lighting, such as LED string, LED strip, LED module etc. ●Indoor/outdoor LED video or irregular screen. |
Series Part No. Gray Scale Voltage RGB Current Package Dimensions Capacitor Reverse connection protection Overvoltage protection WS2814A 8bit 256 gray scale 3.3V-48V 4 Channel 16mA*4, 2KHZ SOP8/ SOT23-8 Black/White No WS2814B 8bit 256 gray s |
|
| 2 | WS2814 Family | WS2814A | SOP8 |  |
Applications
● LED full color decorative lighting, such as LED string, LED strip, LED module etc. ●Indoor/outdoor LED video or irregular screen. |
WS2814A 8bit 256 gray scale 3.3V-24V 4 Channel 16mA*4 SOP8/ SOT23-8 Black/White
|
|
| 3 | WS2814 Family | WS2814B | SOP10 | |
Applications
● LED full color decorative lighting, such as LED string, LED strip, LED module etc. ●Indoor/outdoor LED video or irregular screen. |
Part No. Gray Scale Voltage RGB Channel Q’TY RGB Channel Current Package Dimension Plastic sealing body color Dual-signal WS2814B 8bit 256 gray scale 3.3V-24V 4 Channel 16mA*4,4KHZ SOP10 Black Yes |
|
| 4 | WS2814 Family | WS2814C | SOP8/SOT23-8 |  |
Applications
● LED full color decorative lighting, such as LED string, LED strip, LED module etc. ●Indoor/outdoor LED video or irregular screen. |
Series Part No. Gray Scale Voltage RGB Current Package Dimensions Capacitor Reverse connection protection Overvoltage protection WS2814C 8bit 256 gray scale 3.3V-24V 4 Channel 16mA*4, 4KHZ SOP8/SOT23-8 Black/White No |
|
| 5 | WS2814 Family | WS2814D | SOP8/SOT23-8 | |
Applications
● LED full color decorative lighting, such as LED string, LED strip, LED module etc. ●Indoor/outdoor LED video or irregular screen. |
Series Part No. Gray Scale Voltage RGB Current Package Dimensions Capacitor Reverse connection protection Overvoltage protection WS2814D 8bit 256 gray scale 3.3V-48V 4 Channel RGB:16mA,W:60mA SOP8/SOT23-8 Black/White No |
|
| 6 | WS2814 Family | WS2814F | SOT23-8 |  |
Applications
● LED full color decorative lighting, such as LED string, LED strip, LED module etc. ●Indoor/outdoor LED video or irregular screen. |
WS2814F 8bit 256 gray scale 3.3V-24V 4 Channel 16mA*4 SOP8/ SOT23-8 Black/White
|
